Dapr 源码解析 | Sidecar Injector

·4 mins
Golang Dapr Cloud Native
Table of Contents

dapr sidecar injector 是 dapr 几个独立软件之一, 功能是在 k8s 环境为用户服务注入 dapr runtime sidecar 容器.

总览 #

想要看懂 injector 工作原理, 我们需要从部署入手, 因为它是和 k8s 很多功能一起完成的.

首先通过 helm 生成一份部署配置文件:

helm repo add dapr https://dapr.github.io/helm-charts/
helm repo update
helm template dapr dapr/dapr > dapr.yaml

dapr.yaml 就是生成出来的部署配置文件.

搜寻 dapr-sidecar-injector 相关的配置, 可以看到除了常规的 Deployment 和 Service 配置还有个配置:

apiVersion: admissionregistration.k8s.io/v1
kind: MutatingWebhookConfiguration
metadata:
  name: dapr-sidecar-injector
  labels:
    app: dapr-sidecar-injector
webhooks:
  - name: sidecar-injector.dapr.io
    clientConfig:
      service:
        namespace: default
        name: dapr-sidecar-injector
        path: '/mutate'
      caBundle: 'xxxx'
    rules:
      - apiGroups:
          - ''
        apiVersions:
          - v1
        resources:
          - pods
        operations:
          - CREATE
    failurePolicy: Ignore
    sideEffects: None
    admissionReviewVersions: ['v1', 'v1beta1']

可以看到配置类型是 MutatingWebhookConfiguration , 它是做什么的呢?

根据上面配置 webhooks 和 rules 配置, 大概能够猜出来: 在 k8s pod 资源创建时, 给 dapr-sidecar-injector service 的路由 /mutate 发送一个 webhook 请求.

查看官方文档 https://kubernetes.io/docs/reference/access-authn-authz/extensible-admission-controllers 可以看到, 确实和猜想的没有太大出入. Mutating admission webhooks 可以定义一个 webhook, 会在对应的时机率先被调用, 并且允许我们对该资源进行修改, 并在修改完成后继续执行相应步骤.

综上所述, 需要 sidecar injector 做的事情就是提供一个 http webhook handler, 收到 pod 创建请求时, 根据 pod 信息为其注入 dapr sidecar 容器(响应相应的 patchOps 修改操作).

源码 #

injector 入口文件为 cmd/injector/main.go .

func main() {
  // ...
  uids, err := injector.AllowedControllersServiceAccountUID(ctx, kubeClient)
  if err != nil {
    log.Fatalf("failed to get authentication uids from services accounts: %s", err)
  }

  injector.NewInjector(uids, cfg, daprClient, kubeClient).Run(ctx)

  shutdownDuration := 5 * time.Second
  log.Infof("allowing %s for graceful shutdown to complete", shutdownDuration)
  <-time.After(shutdownDuration)
}

去掉健康检查服务, 剩下的代码就只是单纯调用 injector.NewInjector 实例化 injector 然后运行.

NewInjector 函数创建了一个 http server 并且添加了 webhook 路由 mux.HandleFunc("/mutate", i.handleRequest) .

handleRequest 会真正处理 webhook 逻辑.

func (i *injector) handleRequest(w http.ResponseWriter, r *http.Request) {
  // 检验请求参数
  // ...
  // 反序列化拿到请求参数
  ar := v1.AdmissionReview{}
  _, gvk, err := i.deserializer.Decode(body, nil, &ar)
  if err != nil {
    log.Errorf("Can't decode body: %v", err)
  } else {
    // 检查账号权限
    if !(utils.StringSliceContains(ar.Request.UserInfo.UID, i.authUIDs) || utils.StringSliceContains(systemGroup, ar.Request.UserInfo.Groups)) {
      log.Errorf("service account '%s' not on the list of allowed controller accounts", ar.Request.UserInfo.Username)
    } else if ar.Request.Kind.Kind != "Pod" { // 排除其他非 pod 资源的请求
      log.Errorf("invalid kind for review: %s", ar.Kind)
    } else {
      // 构造出 pod 资源需要的修改操作
      patchOps, err = i.getPodPatchOperations(&ar, i.config.Namespace, i.config.SidecarImage, i.config.SidecarImagePullPolicy, i.kubeClient, i.daprClient)
      if err == nil {
        patchedSuccessfully = true
      }
    }
  }
  // 根据上述结果构造出 webhook 响应
  // ...
}

除了请求校验和响应构建, 核心就是调用 getPodPatchOperations 函数构造出修改操作 patchOps 后续会作为响应 response.patch 返回, response.patch 为 []byte 类型, JSON 序列化之后会变成 base64 格式字符串.

{
  "apiVersion": "admission.k8s.io/v1",
  "kind": "AdmissionReview",
  "response": {
    "uid": "<value from request.uid>",
    "allowed": true,
    "patchType": "JSONPatch",
    "patch": "W3sib3AiOiAiYWRkIiwgInBhdGgiOiAiL3NwZWMvcmVwbGljYXMiLCAidmFsdWUiOiAzfV0="
  }
}

getPodPatchOperations 函数主要逻辑如下:

  1. 如果 pod dapr.io/enabled 注解不为 true 或者是否已有 dapr sidecar, 直接 return
  2. 根据 pod 注解构建出 sidecar 容器配置
  3. 为用户 app 注入 DAPR_HTTP_PORT 和 DAPR_GRPC_PORT 两个环境变量
func (i *injector) getPodPatchOperations(ar *v1.AdmissionReview,
  namespace, image, imagePullPolicy string, kubeClient *kubernetes.Clientset, daprClient scheme.Interface) ([]PatchOperation, error) {
  // ...
  // 过滤不需要注入的 pod 请求
  if !isResourceDaprEnabled(pod.Annotations) || podContainsSidecarContainer(&pod) {
    return nil, nil
  }
  // ...
  // 通过 dapr 全局配置 crd 读取是否启用 mTLS
  mtlsEnabled := mTLSEnabled(daprClient)
  // 根据 k8s secrets API 读取信任链 cert
  trustAnchors, certChain, certKey = getTrustAnchorsAndCertChain(kubeClient, namespace)
  identity = fmt.Sprintf("%s:%s", req.Namespace, pod.Spec.ServiceAccountName)
  // 构建出 sidecar 容器配置
  sidecarContainer, err := getSidecarContainer(pod.Annotations, id, image, imagePullPolicy, req.Namespace, apiSvcAddress, placementAddress, tokenMount, trustAnchors, certChain, certKey, sentryAddress, mtlsEnabled, identity)
  // ...
  // 如果没有用户容器, 直接创建 dapr sidecar
  if len(pod.Spec.Containers) == 0 {
    path = containersPath
    value = []corev1.Container{*sidecarContainer}
  } else {
    // 有用户容器, 为用户容器注入环境变量
    envPatchOps = addDaprEnvVarsToContainers(pod.Spec.Containers)
    // 容器列表添加 dapr sidecar
    path = "/spec/containers/-"
    value = sidecarContainer
  }

  patchOps = append(
    patchOps,
    PatchOperation{
      Op:    "add",
      Path:  path,
      Value: value,
    },
  )
  // 合并所有 patch 操作, 并返回
  patchOps = append(patchOps, envPatchOps...)

  return patchOps, nil
}

getSidecarContainer 函数会根据上面条件创建出 dapr sidecar, 支持通过很多 dapr.io/ 开头的注解来控制 sidecar 容器参数:

func getSidecarContainer(annotations map[string]string, id, daprSidecarImage, imagePullPolicy, namespace, controlPlaneAddress, placementServiceAddress string, tokenVolumeMount *corev1.VolumeMount, trustAnchors, certChain, certKey, sentryAddress string, mtlsEnabled bool, identity string) (*corev1.Container, error) {
  // ...
  cmd := []string{"/daprd"}

  args := []string{
    "--mode", "kubernetes",
    "--dapr-http-port", fmt.Sprintf("%v", sidecarHTTPPort),
    "--dapr-grpc-port", fmt.Sprintf("%v", sidecarAPIGRPCPort),
    "--dapr-internal-grpc-port", fmt.Sprintf("%v", sidecarInternalGRPCPort),
    "--dapr-listen-addresses", sidecarListenAddresses,
    "--dapr-public-port", fmt.Sprintf("%v", sidecarPublicPort),
    "--app-port", appPortStr,
    "--app-id", id,
    "--control-plane-address", controlPlaneAddress,
    "--app-protocol", getProtocol(annotations),
    "--placement-host-address", placementServiceAddress,
    "--config", getConfig(annotations),
    "--log-level", getLogLevel(annotations),
    "--app-max-concurrency", fmt.Sprintf("%v", maxConcurrency),
    "--sentry-address", sentryAddress,
    fmt.Sprintf("--enable-metrics=%t", metricsEnabled),
    "--metrics-port", fmt.Sprintf("%v", metricsPort),
    "--dapr-http-max-request-size", fmt.Sprintf("%v", requestBodySize),
  }
  // ...
  c := &corev1.Container{
    Name:            sidecarContainerName,
    Image:           daprSidecarImage,
    ImagePullPolicy: pullPolicy,
    SecurityContext: &corev1.SecurityContext{
      AllowPrivilegeEscalation: &allowPrivilegeEscalation,
    },
    Ports:   ports,
    Command: cmd,
    Env: []corev1.EnvVar{
      {
        Name:  "NAMESPACE",
        Value: namespace,
      },
    },
    Args: args,
    ReadinessProbe: &corev1.Probe{
      Handler:             httpHandler,
      InitialDelaySeconds: getInt32AnnotationOrDefault(annotations, daprReadinessProbeDelayKey, defaultHealthzProbeDelaySeconds),
      TimeoutSeconds:      getInt32AnnotationOrDefault(annotations, daprReadinessProbeTimeoutKey, defaultHealthzProbeTimeoutSeconds),
      PeriodSeconds:       getInt32AnnotationOrDefault(annotations, daprReadinessProbePeriodKey, defaultHealthzProbePeriodSeconds),
      FailureThreshold:    getInt32AnnotationOrDefault(annotations, daprReadinessProbeThresholdKey, defaultHealthzProbeThreshold),
    },
    LivenessProbe: &corev1.Probe{
      Handler:             httpHandler,
      InitialDelaySeconds: getInt32AnnotationOrDefault(annotations, daprLivenessProbeDelayKey, defaultHealthzProbeDelaySeconds),
      TimeoutSeconds:      getInt32AnnotationOrDefault(annotations, daprLivenessProbeTimeoutKey, defaultHealthzProbeTimeoutSeconds),
      PeriodSeconds:       getInt32AnnotationOrDefault(annotations, daprLivenessProbePeriodKey, defaultHealthzProbePeriodSeconds),
      FailureThreshold:    getInt32AnnotationOrDefault(annotations, daprLivenessProbeThresholdKey, defaultHealthzProbeThreshold),
    },
  }
  // ...
}

总结 #

在阅读 dapr 源码前, 我是不知道 k8s 支持 MutatingWebhookConfiguration 功能的, 没想到这个功能可以这么简单实现出来. 全局化配置和注解差异化配置也使得 dapr sidecar 容器的很多配置是可控的.

不过 injector 做完工作 sidecar 并不是可用状态, 因为仅仅有 sidecar 容器并不能互相做 grpc 调用, 所以剩下一部分工作还需要 operator 完成, 后续文章再说明.
